Product Details
Place of Origin: GuangZhou, China
Brand Name: RUI - HE
Certification: RoHS, FDA, MSDS, SGS, REACH, PAHS, ISO9001:2016, etc.
Model Number: 9140-30ZA/B
Payment & Shipping Terms
Minimum Order Quantity: 20KG/200KG
Price: Negotiation
Packaging Details: 20 kg pails or 200 kg drums
Delivery Time: 5-15 days
Payment Terms: Western Union, L/C, T/T, Paypal
Supply Ability: 1000 tons per day
Features: |
Fast Curing,strong Adhesion,good Flow Performance,with Excellent Thermal Stability |
Port: |
Guangzhou / Shenzhen |
Ratio: |
1 : 1 |
Certificate: |
FDA. LFGB. ROHS. REACH. ISO 9001 |
Shelf Life: |
12 Months |
Sample: |
Available |
Output: |
1200 Tons Per Month |
Application: |
Suitable For Textile Fabric Printing And Fabri-ribbon Print Products |
Transportation: |
By Air Or By Ship |
Incoterms: |
EXW, FOB, CIF |
Features: |
Fast Curing,strong Adhesion,good Flow Performance,with Excellent Thermal Stability |
Port: |
Guangzhou / Shenzhen |
Ratio: |
1 : 1 |
Certificate: |
FDA. LFGB. ROHS. REACH. ISO 9001 |
Shelf Life: |
12 Months |
Sample: |
Available |
Output: |
1200 Tons Per Month |
Application: |
Suitable For Textile Fabric Printing And Fabri-ribbon Print Products |
Transportation: |
By Air Or By Ship |
Incoterms: |
EXW, FOB, CIF |
Typical Properties
|
RH9140-30ZA/B
|
|||
|
|
Unit
|
Part - A
|
Part - B
|
|
Appearance
|
/
|
tranparent
|
tranparent
|
|
Shore A Hardness
|
A
|
28
|
|
|
Resilience
|
%
|
60
|
|
|
Tensile Strength
|
MPa
|
1.7
|
|
|
Elongation
|
%
|
500
|
|
|
Tear Strength
|
KN/m
|
15
|
|
| Linear Shrinkage | % | 2.2 | |
These figures are for reference only, please contact us for details.
Mixing ratio of components A : B = 10 : 1.
Vulcanization: 150 °C / 5 min
Rui-He 9140-30ZA/B Liquid silicone rubber obtained the following test certificate: RoHS, FDA.21.177, REACH, PAHS, ISO9001:2016, etc
A
Packaging & Storage
Available in 20kg pails or 200kg drums.
Store in a cool, dry place out of direct sunlight, use it within 12 months from the day of manufacture.
As an innovative silicone company, we always pay attention to the balanced development of economic, ecological and social goals. We use the advanced and scientific management concept to establish the "Ruihe" brand and buid a Chinese silicone intergrated solid silicone rubber and liquid silicone rubber, First-class enterprise.
Q: How many kgs of silicone I need to make a mold, like 1m*1m?
A: First, you change the "m" to "cm". Then the V(volume)=100cm(length)*100cm(width)*1.5cm(height or thickness) =15000cm3
→ the density of the liquid silicone is 1.1g/cm3→ the quantity= 15000cm3* 1.1g/cm3=16500g(16.5kg)
Q: How can I know the thickness of the silicone mold?
A: For the pouring way, if you do not have a plaster have a base to keep its shape (like square), then we usually suggest that 2-3cm is enough. If yes, then 1-1.5 cm is enough.
Q: Why is there not enough 25kgs silicone in the drum?
A: V=m/p. because the different of the silicone viscosity, so there will be a little difference. When the viscosity is lower, there will be 26kgs or more. In contrast, there will be 24kgs or little.
If you need to know the prices of our silicone rubbers, please contact us. We do not provide prices in website because prices fluctuate for many reasons.
