PAHS Industrial Grade Liquid Silicone Rubber / Silicone Injection Molding

PAHS Industrial Grade Liquid Silicone Rubber / Silicone Injection Molding

  • High Light

    custom silicone rubber

    ,

    rtv silicone mould making rubber

  • Features
    Body Safe
  • R & D Center
    30 Persons
  • Application
    Industrial
  • Shelflife
    Within 400 Days
  • Feature
    Safety And Environmental Protection
  • Design
    Customized As Requested
  • Package
    20kgs/200kgs
  • Delivery Time
    3-7 Days
  • Hs Code
    31900000
  • Technical Support
    Free
  • Place of Origin
    GuangZhou, China
  • Brand Name
    Rui-He
  • Certification
    RoHS, FDA, MSDS, SGS, REACH, PAHS, ISO9001
  • Model Number
    RH625-0316-05
  • Minimum Order Quantity
    200KG
  • Price
    USD $+3-7/PER Kilograms
  • Packaging Details
    20kg pails OR 200Kg / drums
  • Delivery Time
    5-8days
  • Payment Terms
    L/C, T/T, Western Union
  • Supply Ability
    1200 tons per month

PAHS Industrial Grade Liquid Silicone Rubber / Silicone Injection Molding



silicone injection molding cost _China manufacture_one-stop service



LSR is platinum-cured and natural transparent silicone which is more transparent than solid silicone. Liquid silicone rubber can mixed with pigmentation to produce colorful LSR molded products.





The silicone products we supply include liquid silicone rubber and room temperature vulcanizing silicones.



The products are transformed into silicone elastomers through the process of vulcanization.



Our silicone rubber products deliver excellent performance in the silicone engineering range of products





Product description



Silicone rubber molding is accomplished in five different ways:



1. cast molding,

2. injection molding,

3. compression molding,

4. transfer molding

5. dip molding



Physical Property
Physical properties Testing method Unit RH6250-20 RH6250-40
Appearance

Visual

inspection

/ Transparent Transparent
Viscosity DIN53019 Pa.s

1000000-1600000

1400000-1800000

Hardness GB/T531.1 Shore A 20 40
Proportion GB/T533 g/cm3 1.05 1.10
Tensile Strength GB/T 528 Mpa 6.0 8.5
Elongation GB/T 528 % 700 550
Tear strength GB/T529 KN/m 20 25
Linear shrinkage CGB-T14235.4 % 0.1% 0.1%
Remarks



Ruihe RH6250 SERIES Liquid Silicone Rubber (F-LSR) is specifically designed for liquid injection molding.



The product is supplied as a two component, soft fluorosilicone paste. It heat cures to a 60 durometer material.



The cured rubber product is resistant to a wide variety of solvents and chemicals over a wide temperature range



of -63 to +175°C (-82° to +347°F) under immersion conditions, and up to +225°C (+437°F) in dry heat.



medical mask silicone rubber

silicone rubber medical mask









Application

These grades are particularly suitable for the economical production of large series of injectionmoulded articles.

Parts made from RUI-HE RH6250-50 can be used for technical and pharmaceutical applications.

These articles are also suitable for use in conjunction with foodstuffs.

silicone rubber factory china



Processing

Mixing

Rui-he RH 6250 series Liquid Silicone Rubber is a two-component material supplied  as parts A and B,

which should be combined in a 1:1 ratio. Meter mix equipment which  pumps, meters, and mixes

the two components without the incorporation of air is strongly  recommended for production.


Pot Life

After the A and B components are mixed,  Liquid Silicone  Rubber will remain usable for at least 48 hours at room temperature.

PAHS Industrial Grade Liquid Silicone Rubber / Silicone Injection Molding 3

Storage

The 'Best use before end' date of each batch is shown on the product label.

Storage beyond the date specified on the label does not necessarily mean that the product is no longer usable.

In this case however, the properties required for the intended use must be checked for quality assurance reasons.


Physical properties Testing method Unit RH6250-40A/B RH6250-50A/B RH6250-60A/B RH6250-70A/B RH6250-71A/B
Appearance Visual inspection / Transparent
Viscosity DIN53019 Pa.s 1200 1200 1500 2000 2500/
Hardness GB/T 531.1 Shore A 40 50 60 65 70
Density

GB/T

533

g/cm3 1.11 1.12 1.12 1.13 1.13
Resilience

GB/T

1681

% 55 65 60 55 55
Tensile Strength GB/T 528-2009 Mpa 7.5 9 9.5 9.5 9
Elongation GB/T 528 % 550 550 500 400 350
Tear Strength GB/T 529 KN/m 25 30 35 30 25
Tensile Set GB/T 528 % 2.6 1.7 1.7 0.8 0.8
Linear shrinkage CGB-T14235.4 % 2.5 2.6 2.6 2.5 2.5





silicone rubber factory



PAHS Industrial Grade Liquid Silicone Rubber / Silicone Injection Molding 5
