Highlight:
high temp silicone mold rubber
, heat resistant silicone rubber
High Temperature Liquid Silicone Rubber , Heat Resistant Silicone Rubber
H6250-10® High-Temperature Liquid Silicone Rubber Heat Resistant Silicone Rubber Electronic Heat-Sinking
Description
H6250-10 product is 2-part liquid silicone rubber, catalyzed by platinum, mixing ratio of parts A:B=1:1.
It can be used in the thermally conductive mechanical parts usually worked in high temperature.
Key Features and Benefits
- Excellent dielectric behavior over a wide range of temperatures
- High thermal stability
- Easy pigmentable with the LSR Color Pastes
- High stability to ozone and ultraviolet light
- Excellent aging resistance
- Neutral odor and taste
- Good rebound property
- Rapid vulcanization
- Sensational weather resistance
Typical Properties
| H 6250-10 |
| Appearance |
translucent |
| Viscosity(mPa.s) |
600000-1200000 |
| Density (g/cm3) |
1.07±0.02 |
| Shore A Hardness(A) |
10 ± 2 |
| Tensile Strength(MPa) |
≥ 2.0 |
| Elongation at break(%) |
≥ 800 |
| Tear Strength(KN / m) |
≥ 5.0 |
| Linear Shrinkage(%) |
≤ 0.5 |
| Tensile set (%) |
≥5.2 |
| Rebound (%) |
≥20 |
| Compression set((22 hrs at 175℃) % |
≤25 |
These figures are for reference only, please contact us for details.
Operation instruction
Part A and B are packed in 20kgs pails or 200kgs drums respectively. When operating, part A and B can be injected directly to the heated mold from the original containers by mean of metering and mixing unit. At the mold temperature of 90-150℃, silicone rubber cures within minutes according to the size. The pot life is 3-7days after mixing under 23℃. Clean pipe and machine when machine stoped for a long time.
Applications
Because of the outstanding properties, H6250-10® silicone rubber is particularly suitable for Industrial thermal conductive accessories, swimming caps, food wrappers, and shower heads.
Certificate
Rui-He H6250-10® silicone rubber obtained the following test certificate: RoHS, FDA, REACH, PAHS, ISO9001:2016, etc.
Packaging Method & Delivery date
| Packaging Details |
This kind of rubber is packed in 20kg/plastic barrels or 200KG/iron drum with an inside plastic bag. |
| Port |
HUANGPU GUANGZHOU, |
| Lead Time |
1 – 1000 (Kilograms)
1001 – 10000 (Kilograms)
|
7 days
15 days
|
Storage
Store in a cool, dry place out of direct sunlight, use it within 12 months from the day of manufacture.
Notice
This product cannot be contacted with compounds containing N, P, S to avoid affecting the catalytic effect of platinum.
If you need to know the prices of our silicone rubbers, please contact us. We do not provide prices on the website because prices fluctuate for many reasons.
