High Stability to Ozone Medical Grade Silicone Rubber Medical Technical equipment

Product Details

Place of Origin: Guangzhou,China

Brand Name: RUI - HE

Certification: FDA,MSDS,LFGB,RoHs,ISO9001-2015

Model Number: RH-6250-30YH

Payment & Shipping Terms

Minimum Order Quantity: 20KG/200KG

Price: Negotiation

Packaging Details: 20 kg pails or 200 kg drums

Delivery Time: 5-15 days

Payment Terms: Western Union, L/C, T/T, Paypal,

Supply Ability: 1000 tons per day

Get Best Price
Highlight:

medical grade liquid silicone rubber

,

fast curing silicone rubber

Features:
Excellent Biocompatibility
Material:
100% Medical Grade LSR
Advantage:
15 Years Experience Factory
Incoterms:
EXW, FOB, CIF
Sample:
Available
Port:
Shenzhen / Guangzhou
Appearance:
Translucent
Viscosity:
Low
Type:
Biomedical Material
Packing:
According To Clients' Requirement,20kg/drum
Features:
Excellent Biocompatibility
Material:
100% Medical Grade LSR
Advantage:
15 Years Experience Factory
Incoterms:
EXW, FOB, CIF
Sample:
Available
Port:
Shenzhen / Guangzhou
Appearance:
Translucent
Viscosity:
Low
Type:
Biomedical Material
Packing:
According To Clients' Requirement,20kg/drum
High Stability to Ozone Medical Grade Silicone Rubber Medical Technical equipment



 High Stability to Ozone Medical Grade Silicone Rubber Medical Technical equipment



Description



RuiHe LSR RH6250-30YH is two-component liquid silicone rubber for injection moulding proceses.

RuiHe RH6250-30YH can be used to produce medical technical articles with high transparency and excellent rubber elastic properties.

Application range: sealing elements, diaghragms, bellows, respiratory devices, vibration dampers, tube connectors, pipette nipples, cathters, parts for medical technical equipment, mats.





Typical Properties



RH-6250-30YH

Properties

Unit

A

B

Appearance

/

transparent

transparent

Viscosity

mPa.s

1200000 - 1800000

Density

g/cm3

1.10 ± 0.02

Shore A Hardness

A/JLS

30 ± 2

Tensile Strength

MPa

≥ 7.0

Elongation at break

%

≥ 650

Tear Strength

KN/m

≥ 15

Linear Shrinkage

%

0.5

Tensile set

%

≥ 2.6

Rebound

%

≥ 45

Compression set

(22 hrs at 175℃) %

30



            These figures are for reference only, please contact us for details.





            Typical properties of the vulcanisate:

            The mixing ratio of components A: B = 1: 1.





High Stability to Ozone Medical Grade Silicone Rubber Medical Technical equipment 0

High Stability to Ozone Medical Grade Silicone Rubber Medical Technical equipment 1





Certificates



Rui-He silicone rubber obtained the following test certificate: RoHS, FDA, MSDS, LFGB, ISO9001:2015.





High Stability to Ozone Medical Grade Silicone Rubber Medical Technical equipment 2

High Stability to Ozone Medical Grade Silicone Rubber Medical Technical equipment 3



Packaging & Storage



Packaging Details

This kind of rubber is packed in 20kg/plastic barrels or 200KG/iron drum with the inside plastic bag.

Port

HUANGPU, GUANGZHOU

Lead Time

1 – 1000 (Kilograms)
1001 – 10000 (Kilograms)

7 days
15 days



           Store in a cool dry place out of direct sunlight, use it within 12 months from the day of manufacture.









High Stability to Ozone Medical Grade Silicone Rubber Medical Technical equipment 4





Instructions



Here is a look at the LSR molding process:



1. LSR A + B components typically come in a 5-gallon pail or 55-gallon drum. A process controlled pumping kit presses down on the buckets to force the material into the static mixer and feed into the injection unit.

2. Then, streams of pigment can be added and controlled. In the injection, press material will be mixed together additionally with a screw and pushed forward to create a “shot” of material, or the amount needed to fill the mold.

3. After the material is injected into the mold, it will then stay clamped together to cure the LSR. Then, either an operator or a robot will remove the cured product from the mold and the cycle repeats. It is a very quick efficient process that typically averages 30 seconds.





Why Choose Us?

1. 15 years of manufacturing experience focus on silicone rubber

2. All Products shipped is Up to FDA, RoHS, Reach, LFGB, testing standard

3. Overall quality controlling procedure and perfect service to you

4. Offer to tailor the order accordance with customer's requirement in detail

5. 800 tons solid silicone rubber, 300 tons LSR silicone rubber and 200 tons silicone oil every month

6. Special organic silicon R&D team and precision inspection instruments equipped

7. Automatic manufacturing equipment adopted, which ensure the products shipped quality well largely



High Stability to Ozone Medical Grade Silicone Rubber Medical Technical equipment 5

High Stability to Ozone Medical Grade Silicone Rubber Medical Technical equipment 6




Notice



This product cannot be contacted with compounds containing N, P, S to avoid affecting the catalytic effect of platinum.





High Stability to Ozone Medical Grade Silicone Rubber Medical Technical equipment 7

High Stability to Ozone Medical Grade Silicone Rubber Medical Technical equipment 8







If you need to know the prices of our silicone rubbers, please contact us. We do not provide prices on a website because prices fluctuate for many reasons.
